Envoy-Gateway
Capsule Integration with Harbor
There’s different ways to use Gateway API in a multi-tenant setup. This guide suggested a strong isolated implementation using the Envoy Gateway Project. The Architecture suggested looks something like this:
Each tenant will get it’s own -system Namespace. However that namespace is not managed by the Tenant nor part of it. It’s the namespace where the platform deploys managed services for each Tenant, which are out of bound for TenantOwners.
Registry Overwrite
Management (Crossplane)
The following example shows how you could automate the management of Harbor based Tenants. This assumes you provide a single harbor instance where all Tenants host their Harbor Projects. However this approach requires Crossplane in combindation with the community provider for Harbor.
apiVersion: capsule.clastix.io/v1beta2
kind: GlobalTenantResource
metadata:
name: tenant-harbor-project
spec:
scope: Tenant
resources:
- generators:
- template: |
---
apiVersion: project.harbor.crossplane.io/v1alpha1
kind: Project
metadata:
name: {{$.tenant.metadata.name}}
labels:
projectcapsule.dev/tenant: {{$.tenant.metadata.name}}
spec:
forProvider:
autoSbomGeneration: true
enableContentTrust: true
enableContentTrustCosign: false
name: {{$.tenant.metadata.name}}
public: false
vulnerabilityScanning: true
{{- with $.tenant.data.registryStorageQuota }}
storageQuota: 10
{{- end }}
---
apiVersion: project.harbor.crossplane.io/v1alpha1
kind: RetentionPolicy
metadata:
name: {{$.tenant.metadata.name}}
spec:
forProvider:
rule:
- nDaysSinceLastPull: 5
repoMatching: '**'
tagMatching: latest
- nDaysSinceLastPush: 10
repoMatching: '**'
tagMatching: '{latest,snapshot}'
schedule: Daily
scopeSelector:
matchLabels:
projectcapsule.dev/tenant: {{$.tenant.metadata.name}}
- generators:
- template: |
{{- range $.tenant.status.owners }}
{{- if eq .kind "User" }}
---
apiVersion: project.harbor.crossplane.io/v1alpha1
kind: MemberGroup
metadata:
name: {{$.tenant.metadata.name}}-owner-group-{{.name}}
spec:
forProvider:
groupName: {{.name}}
projectIdSelector:
matchLabels:
projectcapsule.dev/tenant: {{$.tenant.metadata.name}}
role: projectadmin
type: oidc
{{- elseif eq .kind "User" }}
---
apiVersion: project.harbor.crossplane.io/v1alpha1
kind: MemberUser
metadata:
name: {{$.tenant.metadata.name}}-owner-user-{{.name}}
spec:
forProvider:
projectIdSelector:
matchLabels:
projectcapsule.dev/tenant: {{$.tenant.metadata.name}}
role: projectadmin
userName: {{.name}}
{{- end }}
